Diameter of sphere is$D=0.70m$

Height of the millipede is $H_p=2.0m$

Distance ofmillipede is$p=1.0m$

As the outer surface of the sphere is shiny, note that it is a convex mirror and using the mirror equation considering the negative focal length, we will get the required answer.

Focal length of the spherical mirror is $f=\frac{R}{2}$as:

$\frac{1}{p}+\frac{1}{i}=\frac{1}{f}$

Magnification$m=-\frac{i}{p}=\frac{H_i}{H_p}$

Diameter of sphere is $D=0.70m$

Then radius of sphere will be $R=0.35m$

Focal length of spherical mirror is$=\frac{R}{2}=0.175$

The mirror is convex. Therefore, $f=-0.175$

$\begin{array}{l}\frac{1}{p}+\frac{1}{i}=\frac{1}{f}\\ \frac{1}{1.0m}+\frac{1}{0.175m}=\frac{-1}{i}\\ -\frac{1}{i}=6.7142\\ i≈-0.15m\end{array}$

Distance of image from the surface,$i=0.15m$

Consider the formula for the magnification as:

$\begin{array}{l}m=\frac{i}{p}\\ =-\left(\frac{-115}{1}\right)\\ =0.15\end{array}$

Consider the condition as:

$m>0$

$\begin{array}{c}m=\frac{H_i}{H_p}\\ =\frac{H_i}{2.0}\end{array}$

Solve further as:

$\begin{array}{c}{H}_i=0.15×2\\ =0.30m\end{array}$

Height of image$H_i=0.30m$

Consider the value of the magnification$m=0.15>0$

The image will be upright or not inverted (NI).
