You inflate the front tires on your car to28psi. Later, you measure your blood pressure, obtaining a reading of 120/80 , the readings being in mmHg. In metric countries (which is to say, most of the world), these pressures are customarily reported in kilopascals(kPa). In kilopascals, (a) what is your tire pressure? And (b) what is your blood pressure?

Short Answer

Expert verified

a) The tire pressure is 192.4kPa.

b) The blood pressure is 15.9kPaor 10.6kPa.

Step by step solution

01

The given data

  1. Pressure of tire,pt=28psior28lb/in2
  1. High and low blood pressure,pb=120mmHgand80mmHg
02

Understanding the concept of pressure

We can use the dimensional analysis concept to find the pressure in tire and blood in kPa. Using conversion factors between psilb/in2 andlb/in2 between Pa and , we can findthepressure in the tire in kPa. Then using the conversion factor between mm Hg and Pa, we can find the blood pressure in kPa.

Formula:

Pressure on a body by force F on an area A,

p=FA (i)

03

a) Calculation for tire pressure in kPa

pt=28lb/in2×1.01×105Pa14.7lb/in2∵1atm=1.01×105Pa=lb/in2=192.4kPa Hence, the tire pressure value is 192.4 kPa.

04

b) Calculation for blood pressure in kPa

Calculation for 120 mmHg:

pb=120mmHg×1.01×105Pa760mmHg∵1atm=1.01×105Pa=lb/in2=15.9kPaCalculation for 80 mmHg:

pb=80mmHg×1.01×105Pa760mmHg∵1atm=1.01×105Pa=lb/in2=10.6kPa Hence, the blood pressure values are 15.9 kPa and 10.6 kPa for 120mmHg and 80mmHg respectively.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Water is moving with a speed of 5.0m/sthrough a pipe with a cross-sectional area of4.0\mathrm{~cm}^{2}.The water gradually descends 10mas the pipe cross-sectional area increases to 8.0cm2.

(a) What is the speed at the lower level?

(b) If the pressure at the upper level is 1.5×105Pa, What is the pressure at the lower level?

In Figure, water stands at depth D=35.0mbehind the vertical upstream face of a dam of width W=314m .(a)Find the net horizontal force on the dam from the gauge pressure of the water.(b)Find the net torque due to that force about a horizontal line through parallel to the (long) width of the dam. This torque tends to rotate the dam around that line, which would cause the dam to fail. (c)Find the moment arm of the torque.

Fresh water flows horizontally from pipe section 1 of cross-sectional area A1into pipe section 2 of cross-sectional area A2. Figure gives a plot of the pressure difference p2-p1versus the inverse area squared A,-2that would be expected for a volume flow rate of a certain value if the water flow were laminar under all circumstances. The scale on the vertical axis is set by ps=300kN/m2. For the conditions of the figure,

(a) what is the value of A2and

(b) what is the value of the volume flow rate?

A water pipe having a 2.5cminside diameter carries water into the basement of a house at a speed of 0.90m/sand a pressure of 170kPa.

(a) If the pipe tapers to 1.2cmand rises to the second floor 7.6mabove the input point, what is the speed and

(b) If the pipe tapers to 1.2cmand rises to the second floor 7.6mabove the input point, what is the water pressure at the second floor?

Two identical cylindrical vessels with their bases at the same level each contain a liquid of density1.30×103kg/m3. The area of each base is4.00cm2, but in one vessel the liquid height is 0.854 mand in the other it is 1.560 m. Find the work done by the gravitational force in equalizing the levels when the two vessels are connected.
