The height of the Tower of Pisa,$\text{h}=59.1\text{″¾}$.

The diameter of the Tower of Pisa,$D=7.44\text{″¾}$.

The displacement of the Tower was measured from the top, $\text{x}=4.01\text{″¾}$.

Using the concept of center of gravity, you can calculate the maximum displacement allowed for tilting of the tower building. Any object can be steady until the center of gravity has the support of the base. The formulas used are given below.

$\begin{array}{l}\mathbf{x}\mathbf{=}\mathbf{h}\mathbf{×}\mathbf{s}\mathbf{i}\mathbf{n}\mathbf{θ}\\ \mathbf{t}\mathbf{a}\mathbf{n}\mathbf{θ}\mathbf{=}\mathbf{}\frac{\mathbf{r}}{\mathbf{y}}\end{array}$

We need to calculate the radius of the Tower, so

$\begin{array}{c}r=\frac{D}{2}\\ =\frac{7.44\text{ }m}{2}\\ =3.72\text{″¾}\end{array}$

Any building will remain steady until the center of mass has the support of the base. The center of mass of the Tower can be assumed at the midpoint of the Tower.

So, we have

$\begin{array}{c}y=\frac{h}{2}\\ =\frac{59.1\text{ }m}{2}\\ =29.55\text{″¾}\end{array}$

And,

x = r = 3.72 m

The Tower will be on the verge of toppling when the center of mass is at the side of the

Cylinder.

So, we can write as,

$tan\mathrm{θ}=\frac{r}{y}$

Using this equation, we can find the angle as,

$\begin{array}{c}\mathrm{θ}=(\frac{3.72\text{ }m}{29.55\text{ }m})\\ =7.18°\end{array}$

Now, the distance measured from the top of the Tower at the verge of toppling will be,

$\begin{array}{c}x=h×sin\mathrm{θ}\\ =59.1×sin7.18°\\ =7.38\text{″¾}\end{array}$

So, the additional distance before the tower can fall, is,

$\begin{array}{c}d=7.38\text{ }m−4.01\text{ }m\\ =3.37\text{″¾}\end{array}$

As calculated in (a), the angle made with the vertical is,

$\mathrm{θ}=7.18°$
