In Fig. 12-68, an 817 kg construction bucket is suspended by a cable Athat is attached at O to two other cables Band C, making anglesθ1=51.0°andθ2=66.0°with the horizontal. Find the tensions in (a) cable A, (b) cable B, and (c) cable C. (Hint:To avoid solving two equations in two unknowns, position the axes as shown in the figure.)

Short Answer

Expert verified

a) The tension in Cable A,TA=8.01×103 N

b) The tension in Cable B,TB=3.65×103 N

c) The tension in Cable C,TC=5.66×103 N

Step by step solution

01

Listing the given quantities

θ1=51°

θ2=66°

Massofbucket m=817 kg

Hint: To avoid solving two equations in two unknowns, position the axes as shown in the figure.

02

Understanding the concept of force and tension

The bucket is tied to Cable A at point O. So from the free body diagram of the bucket, we can find the tension in Cable A.

Now as all the cables are attached at point O, they will be at equilibrium. So using equilibrium conditions, we can find the tension in Cable B and C.

Equations:

∑Fx=0

∑Fy=0

03

(a) Calculations of tension in cable A

Weightofbucket=massbucket×g=817 kg×9.8 m/s2=8.01×103 N

Free body diagram for the bucket:

At point A,

TA-weightofbucket=0

TA=weightofbucket

TA=8.01×103 N

Therefore the tension in Cable A,TA=8.01×103 N

04

(b) Calculations of tension in cable B

Using the coordinates as described in the diagram.

We can say that cable A makes an angleθ2with the negative y-axis, cable B makes an angle of27°with the positive y-axis and cable C is along the positive x-axis.

As the system is in equilibrium,the sum of the forces along the x and y axis should be equal to zero.

Therefore, we can write,

TBcos27°−TAcos66°=0TBcos27°=TAcos66°=TB=TAcos66°cos27°TB=3.65×103 N

The tension in Cable B,TB=3.65×103 N

05

(C) Calculations of tension in cable C

Similarly, for the x-axis, we can write,

TC+TBsin27°-TAsin66°=0TC=TAsin66°−TBsin27°TC=(8.01×102 N×sin66°-3.65×103 N×sin27°)TC=5.66×103 N

The tension in Cable C isTC=5.66×103 N
