1. The inductance of the LC circuit,$L=50\text{mH or}50×{10}^{-3}\text{H}$
2. The capacitance of the LC circuit,$C=40\mathrm{μ¹ó}=40×{10}^{-6}\mathrm{F}$
3. Initially, the current is at maximum.

Angular frequency is also known as radial frequency, measured as the angular displacement per unit time. By using the formula for angular frequency in terms of the period, we will find the time taken for charging the capacitor fully.

Formulae:

The resonance frequency of an LC circuit, $\mathrm{Ó\neg }=\frac{1}{\sqrt{LC}}$ (i)

The angular frequency of an oscillation, $\mathrm{Ó\neg }=\frac{2\mathrm{Ï€}}{T}$ (ii)

From equations (i) and (ii), we can get the period of oscillations as follows:

$\begin{array}{rcl}T& =& 2\mathrm{π}\sqrt{LC}\\ & =& 2×3.14\sqrt{50×{10}^{-3}×4×{10}^{-6}}\\ & =& 0.0028\text{sec}\\ & & \end{array}$

The time required for the charge to rise from zero to its first maximum value is one-quarter of a period. Thus, the required time for the capacitor being fully charged can be given as:

$$\begin{gathered} t=\frac{T}{4} \\ =\frac{0.0028}{4} \\ =7.0×{10}^{-4}\text{sec} \end{gathered}$$

Hence, the time required to fully charge the capacitor for the first time is $7.0×{10}^{-4}\text{sec}$.
