1. Effective resistance $R=32.0\text{Ω}$
2. Inductive reactance$X_L=45.0\text{Ω}$
3. RMS value of voltage${\mathrm{Î\mu }}_{rms}=420\text{V}$

The RMS value of current means the square root of mean of square of value of current. The resistance offered in the path of current by the inductor is known as inductive reactance.

The rms current of a circuit,

$I_{rms}=\frac{{\mathrm{Î\mu }}_{rms}}{Z}$ ...(i)

The impedance of the$LR$circuit for the driving frequency${\mathrm{Ó\neg }}_d$

$Z=\sqrt{R^2+{X_L}^2}$ ...(ii)

The impedance value of the circuit can be given using equation (ii) as follows:

$Z=\sqrt{R^2+{X_L}^2}$

Now, substituting the above value in equation (i), we can get the value of rms current for the given data as follows:

$$\begin{gathered} I_{rms}=\frac{{\mathrm{Î\mu }}_{rms}}{\sqrt{R^2+{\left(X_L\right)}^2}} \\ =\frac{420\text{V}}{\sqrt{{\left(45\text{Ω}\right)}^2+{\left(32\text{Ω}\right)}^2}} \\ =7.61\text{A} \end{gathered}$$

Hence, the value of the current is localid="1662764908957" $7.61\text{A}$.
