1. The electric charge of the proton,${\mathrm{q}}_{\mathrm{p}}=1.6脳{10}^{-19}\mathrm{C}$
2. Strength of the electric field at A with direction,role="math" localid="1657278375354" ${\mathrm{E}}_{\mathrm{A}}=(-40\mathrm{N}/\mathrm{C})\hat{\mathrm{i}}$
3. The electric field lines on the left are twice to that of the right.

Using the concept of electric field relation with force per unit charge, we can get the required value of the force and the electric field at B.

Formula:

The force on a charged particle in an electric field, $\stackrel{鈫�}{F}=q_0\mathrm{E}$ (1)

where ${\mathrm{q}}_0$= electric charge on the particle, and $\stackrel{鈫�}{\mathrm{E}}$= Strength of the electric field

As the force at A is orienting our x-axis rightward (so$\hat{\mathrm{i}}$points right in the figure), we can calculate the electric field at A using equation (1) as follows:

$$\begin{gathered} \stackrel{鈫�}{F}=(+1.6脳{10}^{-19}\mathrm{C})(-40\mathrm{N}/\mathrm{C}\hat{\mathrm{i}}) \\ =(-6.4脳{10}^{-18}\mathrm{N})\hat{\mathrm{i}} \end{gathered}$$

Hence, the magnitude of the force on the proton is role="math" localid="1657279039599" $64x{10}^{-18}\mathrm{N}$and its direction$\left(-\stackrel{铃�}{\mathrm{i}}\right)$ is leftward.

The field strength is proportional to the 鈥渃rowdedness鈥� of the field lines. So, from the given data, we conclude that

$\begin{array}{l}{\mathrm{E}}_{\mathrm{A}}=2{\mathrm{E}}_{\mathrm{B}}\\ {\mathrm{E}}_{\mathrm{B}}=\frac{{\mathrm{E}}_{\mathrm{A}}}{2}\\ =20\mathrm{N}/\mathrm{C}\end{array}$

Hence, the magnitude of the electric field is$20\mathrm{N}/\mathrm{C}$
