Whatever supports a load, it must supply an upward force equal to the weight of the load. This upward force is called the normal force.

The tension which acts upwards must be equal to the weight of the spider can be written as,

\(T = mg\)

Here, T is the tension in the vertical strand, m is the mass of the spider, and g is the acceleration due to gravity.

Substitute 8x10^-5 kg for m and 9.8 m/s² for g in the above expression, and we get,

\(\begin{array}{l}T = 8 \times {10^{ - 5}}\;{\rm{kg}} \times 9.8\;{\rm{m/}}{{\rm{s}}^{\rm{2}}}\\T = 7.84 \times {10^{ - 4}}\;{\rm{N}}\end{array}\)

Hence, the tension in the vertical strand is 7.84x10^-4 N.

Write the expression or calculate the tension in the horizontal strand as:

\(T' = \frac{{mg}}{{2\sin \theta }}\)

Here, T’ is the tension in the horizontal strand and\(\theta \)is the angle at which the strand sags below the horizontal.

Substitute 8x10^-5 kg for m, 12⁰ for\(\theta \), and 9.8 m/s² for g in the above expression, and we get,

\(\begin{array}{c}T' = \frac{{8 \times {{10}^{ - 5}}\;{\rm{kg}} \times 9.8\;{\rm{m/}}{{\rm{s}}^{\rm{2}}}}}{{2 \times \sin {{12}^\circ }}}\\ = \frac{{7.84 \times {{10}^{ - 4}}\;{\rm{N}}}}{{2 \times 0.2079}}\\ = 1.89 \times {10^{ - 3}}\;{\rm{N}}\end{array}\)

Hence, the tension in the horizontal strand is 1.89x10^-3 N.

\(\begin{array}{c}\frac{{T'}}{T} = \frac{{1.89 \times {{10}^{ - 3}}}}{{7.84 \times {{10}^{ - 4}}}}\\ = 2.4\end{array}\)

Hence, the tension in the horizontal strand is 2.4 times more than that in the vertical strand.
