Chapter 10: Q 70. (page 655)

Semi elliptical Arch Bridge The arch of a bridge is a semi ellipse with a horizontal major axis. The span is $30$ feet, and the top of the arch is $10$ feet above the major axis. The roadway is horizontal and is $2$ feet above the top of the arch. Find the vertical distance from the roadway to the arch at $5$ -foot intervals along the roadway.

Short Answer

Expert verified

The vertical distance from the roadway to arch at $5$ foot intervals are $2.57$ feet , $4.54$ feet and $12$ feet.

Step by step solution

Step 1. Given information.

The major axis of the arch is parallel to the x-axis. since the span of the arch is $30$ feet, this means

$a = \frac{30}{2} a = 15$

The top of the arch is $10$ feet above the major axis.This means $b = 10$ .

The road ways lies $2$ feet above top of the arch.Thus, the coordinates of the center are $(0, - 12)$ .

Step 2. The equation of the ellipse and graph of the arch.

The equation of the ellipse is $\frac{{(x - 0)}^{2}}{225} + \frac{{(y + 12)}^{2}}{100} = 1$

The graph of the arch is

Step 3. Vertical distance from roadway to arch.

Now, putting $x = 5$ in the equation of ellipse

role="math" localid="1646806151750"

\frac{25}{225} + \frac{{(y + 12)}^{2}}{100} = 1 {(y + 12)}^{2} = \frac{800}{9} y = 卤 \frac{20 \sqrt{2}}{3} - 12 y = - 2.57, - 21.42

We have considered only the upper semi- ellipse constituting the arch.

Putting $x = 10$ in the equation we get.

role="math" localid="1646806607812" $\frac{100}{225} + \frac{{(y + 12)}^{2}}{100} = 1 {(y + 12)}^{2} = \frac{500}{9} y = 卤 \frac{10 \sqrt{5}}{3} - 12 y = - 4.54$

For $x = - 15$ and $x = 15$ $y = - 12$

Thus, the vertical distances from the roadway to arch at $5$ foot intervals are $2.57 f e e t, 4.54 f e e t$ and $12 f e e t$ .
