Chapter 3: Q 3.4-1E (page 115)

An object of mass 5 kg is released from rest 1000 m above the ground and allowed to fall under the influence of gravity. Assuming the force due to air resistance is proportional to the velocity of the object with proportionality constant b = 50 N-sec/m, determine the equation of motion of the object. When will the object strike the ground?

Short Answer

Expert verified
  • The equation of motion of the object isx(t)=0.981t-0.0981(1-e-10t)m
  • The time taken by the object is1019 sec.

Step by step solution

01

Find the equation of motion of an object

The given values are m = 5, g = 9.81,v0= 0, b = 50,

The equation of motion isrole="math" localid="1664170601861" x(t)=mgtb+mbv-mgb1-e-btm

Put all the given values

5(9.81)t50+550(0-5(9.81)50)(1-e-50t5)(9.81)t10-(9.81)100)(1-e-10t)x(t)=(9.81)t10-(9.81)100)(1-e-10t)x(t)=0.981t-0.0981(1-e-10t)m

Hence the equation of motion is role="math" localid="1664170624317" x(t)=0.981t-0.0981(1-e-10t)m

02

Finding when will the object strike the ground

1000=0.981t-0.0981(1-e-10t)1000=0.981t-0.0981(Becausevalueofissosmallsoneglecting)1000+0.0981=0.981t1000.0981=0.981tt=1000.0981/0.981t=1019sec

Hence, the object will strike the ground in 1019 sec.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Early Monday morning, the temperature in the lecture hall has fallen to 40掳F, the same as the temperature outside. At7:00a.m., the janitor turns on the furnace with the thermostat set at70掳F. The time constant for the building is1k=2鈥�hrand that for the building along with its heating system is1k1=12鈥�hr. Assuming that the outside temperature remains constant, what will be the temperature inside the lecture hall at8:00a.m.? When will the temperature inside the hall reach65掳F?

The air in a small room 12 ft by 8 ft by 8 ft is 3% carbon monoxide. Starting at t = 0, fresh air containing no carbon monoxide is blown into the room at a rate of 100ft3/min. If air in the room flows out through a vent at the same rate, when will the air in the room be 0.01% carbon monoxide?

Local versus Global Error. In deriving formula (4) for Euler鈥檚 method, a rectangle was used to approximate the area under a curve (see Figure 3.14). With

\({\bf{g(t) = f(t,f(t))}}\), this approximation can be written as \(\int\limits_{{{\bf{x}}_{\bf{n}}}}^{{{\bf{x}}_{{\bf{n + 1}}}}} {{\bf{g(t)dt}} \approx {\bf{hg(}}{{\bf{x}}_{\bf{n}}}{\bf{)}}} \)where \({\bf{h = }}{{\bf{x}}_{{\bf{n + 1}}}}{\bf{ - }}{{\bf{x}}_{\bf{n}}}\) .

  1. Show that if g has a continuous derivative that is bounded in absolute value by B, then the rectangle approximation has error\(\left( {\bf{O}} \right){{\bf{h}}^{\bf{2}}}\); that is, for some constant M, \(\left| {\int\limits_{{{\bf{x}}_{\bf{n}}}}^{{{\bf{x}}_{{\bf{n + 1}}}}} {{\bf{g(t)dt - hg(}}{{\bf{x}}_{\bf{n}}}{\bf{)}}} } \right| \le {\bf{M}}{{\bf{h}}^{\bf{2}}}\).This is called the local truncation error of the scheme. [Hint: Write \(\int\limits_{{{\bf{x}}_{\bf{n}}}}^{{{\bf{x}}_{{\bf{n + 1}}}}} {{\bf{g(t)dt - hg(}}{{\bf{x}}_{\bf{n}}}{\bf{)}}} {\bf{ = }}\int\limits_{{{\bf{x}}_{\bf{n}}}}^{{{\bf{x}}_{{\bf{n + 1}}}}} {\left[ {{\bf{g(t)dt - g(}}{{\bf{x}}_{\bf{n}}}{\bf{)}}} \right]{\bf{dt}}} \). Next, using the mean value theorem, show that\(\left| {{\bf{g(t)dt - g(}}{{\bf{x}}_{\bf{n}}}{\bf{)}}} \right| \le {\bf{B}}\left| {{\bf{t - }}{{\bf{x}}_{\bf{n}}}} \right|\) . Then integrate to obtain the error bound\(\left( {\frac{{\bf{B}}}{{\bf{2}}}} \right){{\bf{h}}^{\bf{2}}}\).]
  2. In applying Euler鈥檚 method, local truncation errors occur in each step of the process and are propagated throughout the further computations. Show that the sum of the local truncation errors in part (a) that arise after n steps is (O)h. This is the global error, which is the same as the[ss1] [m2] convergence rate of Euler鈥檚 method.


If the object in Problem 2 is released from rest 30ftabove the ground instead of 500ft, when will it strike the ground? [ Hint:Use Newton鈥檚 method to solve for t ]

During the summer the temperature inside a van reaches 55掳C, while that outside is a constant35掳C. When the driver gets into the van, she turns on the air conditioner with the thermostat set at16掳C. If the time constant for the van is1k=2鈥�hrand that for the van with its air conditioning system is1k1=13鈥�hr, when will the temperature inside the van reach 27掳C?
