Ordinary Glasses: Ordinary glasses are worn in front of the eye and usually 2.0 cm in front of the eyeball. Suppose that the person in previous exercise prefers ordinary glasses to contact lenses. What focal length lenses are needed to correct his vision, and what is their power in diopters?

Short Answer

Expert verified

The farsightedness can be corrected by using a converging lenses of focal length +49.45 and power +2.022 diopters.

Step by step solution

01

Basic definition

Thin Lens formula:

1u+1v=1f

Here,

u = Object distance from lens

v = Image distance from lens

f = Focal length of the lens

Sign Convention:

  1. Object Distance (u): (+) in front of lens; (-) in the back of lens
  2. Image Distance (v): (-) in front of lens; (+) in the back of lens
  3. Focal Length (f): (+) for convergent (convex) lens; (-) for divergent (concave) lens

Power of a lens is defined as the reciprocal of its focal length. Thus, converging or convex lens have positive powers and diverging or concave lens have negative powers.

02

Focal length and Power of the Lens

Object distance, u = (+25.0-2)cm

=+23cm

Image distance, v = (+45.0+2)cm

= - 43 cm

By using lens formula,

⇒1+23+1-43=1f⇒43-2343*23=1f⇒f=+45.49cm

Power of the lens is given by

⇒Power,P=1Focallength,f⇒P=1f=10049.45cm=2.022diopters

Therefore, the farsightedness can be corrected by using a converging glasses of focal length +49.45 cm and power +2.022 diopters.
