A 55-kg runner runs around the edge of a horizontal turntable mounted on a vertical, frictionless axis through its center. The runner’s velocity relative to the earth has magnitude 2.8 m/s. The turntable is rotating in the opposite direction with an angular velocity of magnitude 0.20 rad/s relative to the earth. The radius of the turntable is 3.0 m, and its moment of inertia about the axis of rotation is80kgm2. Find the final angular velocity of the system if the runner comes to rest relative to the turntable. (You can model the runner as a particle.)

Short Answer

Expert verified

The required angular velocity of the system is Ó¬'=0.776rad/s2.

Step by step solution

01

Angular momentum of the system

It is given that the mass of the person as m=55kg, runners speed relative to the earth as vf=2.8m/s, angular velocity of the turntable as Ó¬=0.20rad/s, radius of the turntable as r=3.0m and the moment of inertia asI=80kgm2 .

02

Concept

By the conservation of angular momentum, Li=Lf. The initial angular momentum due to the person and the turntable is Li=mrvr-IÓ¬.

The moment of inertia of the system is I'=mr2+I then the final angular momentum is given by,

Lf=I'Ó¬'=mr2+IÓ¬'

03

Angular velocity of the system

Since,Li=Lfthen,

role="math" localid="1667991534420" mrvr-IӬ=mr2+IӬ'⇒Ӭ'=mrvr-IӬmr2+I

Now, substitute all the known values and simplify.

Ӭ′=mrvr−IӬmr2+I=(55kg)(3.0m)(2.8m/s)−80kgm2(0.20rad/s)(55kg)(3.0m)2+80kgm2=462kgm2/s−80kgm2(0.20rad/s)165kgm2+80kgm2=0.776rad/s2

Therefore, the angular velocity of the given system is Ó¬'=0.766rad/s2.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

A closed and elevated vertical cylindrical tank with diameter 2.00 m contains water to a depth of 0.800 m. A worker accidently pokes a circular hole with diameter 0.0200 m in the bottom of the tank. As the water drains from the tank, compressed air above the water in the tank maintains a gauge pressure of 5 X 103Pa at the surface of the water. Ignore any effects of viscosity. (a) Just after the hole is made, what is the speed of the water as it emerges from the hole? What is the ratio of this speed to the efflux speed if the top of the tank is open to the air? (b) How much time does it take for all the water to drain from the tank? What is the ratio of this time to the time it takes for the tank to drain if the top of the tank is open to the air?

How many times does a typical person blink her eyes in a lifetime?

Starting from a pillar, you run 200 m east (the +x-direction) at an average speed of 5.0 m/s and then run 280 m west at an average speed of 4.0 m/s to a post. Calculate (a) your average speed from pillar to post and (b) youraverage velocity from pillar to post.

An astronaut has left the International Space Station to test a new space scooter.

Her partner measures the following velocity changes, each taking place in a 10-sinterval.

What are the magnitude, the algebraic sign, and the direction of the average acceleration in each interval?

Assume that the positive direction is to the right.

(a) At the beginning of the interval, the astronaut is moving toward the right along the x-axis at 15.0m/s, and at the end of the interval she is moving toward the right at5.0m/s .

(b) At the beginning she is moving toward the left atrole="math" localid="1655276110547" 5.0m/s , and at the end she is moving toward the left at 15.0m/s.

(c) At the beginning she is moving toward the right at , and at the end she is moving toward the left atrole="math" localid="1655276636193" 15.0m/s .

A plastic ball has radius 12.0 cm and floats in water with 24.0% of its volume submerged. (a) What force must you apply to the ball to hold it at rest totally below the surface of the water? (b) If you let go of the ball, what is its acceleration the instant you release it?
