A proton is placed in a uniform electric field and thenreleased. Then an electron is placed at this same point and released.Do these two particles experience the same force? The sameacceleration? Do they move in the same direction when released?

Short Answer

Expert verified

The two particles experience the same force but in opposite direction.

No, they don’t have the same acceleration.

When released, they move in an opposite direction.

Step by step solution

01

Definition of the acceleration

The rate at which an object's velocity changes with function of time is called acceleration.

The acceleration when the velocity is zero is called initial acceleration. The acceleration from the Newton’s second law is given by,

a=Fm

Here, mis the mass, and Fis the force.

02

Calculation of the force, the acceleration and the direction exerted by the two particles

The charges of the positively charged particle-proton and the negatively charged particle-electron are equal in magnitude but opposite in sign.On each particle, the electric field produces the same magnitude of forces but in opposing directions.

Since the proton has more mass, its acceleration is less than that of an electron. This is because acceleration and mass are inversely related with constant F, a=Fm.

Protons accelerate in the direction of the electric field but with a tiny magnitude, while electrons accelerate in the opposite direction.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Question: A +2.00nC point charge is at the origin, and a second -5.00nC point charge is on the x-axis at x = 0.800 m. (a) Find the electric field (magnitude and direction) at each of the following points on the x-axis: (i) x = 0.200 m; (ii) x = 1.20 m; (iii) x = -0.200 m. (b) Find the net electric force that the two charges would exert on an electron placed at each point in part (a).

Questions: A conductor that carries a net charge has a hollow, empty cavity in its interior. Does the potential vary from point to point within the material of the conductor? What about within the cavity? How does the potential inside the cavity compare to the potential within the material of the conductor?

A metal bar with length L, mass m, and resistance R is placed on frictionless metal rails that are inclined at an angle f above the horizontal. The rails have negligible resistance. A uniform magnetic field of magnitude B is directed downward as shown in Fig. P29.69 . the bar is released from rest and slides down the rails. (a) Is the direction of the current induced in the
bar from a to b or from b to a? (b) What is the terminal speed of the bar? (c) What is the induced current in the bar when the terminal speed has been reached? (d) After the terminal speed has been reached, at what rate is electrical energy being converted to thermal energy in the resistance of the bar? (e) After the terminal speed has been reached, at what rate is work being done on the bar by gravity? Compare your answer to that in part (d)


Question: In the circuit shown in Fig. E26.47 each capacitor initially has a charge of magnitude 3.50 nC on its plates. After the switch S is closed, what will be the current in the circuit at the instant that the capacitors have lost 80.0% of their initial stored energy?

Current passes through a solution of sodium chloride. In

1.00s,2.68×1016Na+ions arrive at the negative electrode and3.92×1016CI-

ions arrive at the positive electrode. (a) What is the current passing between

the electrodes? (b) What is the direction of the current?
