The polygon having 12 sides, have the charges present at each of its corner. A test charge is present at the center of the polygon having 12 sides. The force and electric filed at the test charge is to be evaluated.

Electric force exerted by charge$q$on charge $Q$is proportional to theproduct of the two charge and inversely proportional to the square of thedistance between them as,

$\mathit{F}\mathbf{=}\frac{\mathbf{1}}{\mathbf{4}\mathbf{蟺}{\mathbf{蔚}}_{\mathbf{0}}}\mathbf{}\frac{\mathbf{q}\mathbf{Q}}{{\mathbf{r}}^{\mathbf{2}}}$.

If two charge $q$and $Q$are placed at a distance $r$apart. Then electric force exerted by charge $q$on charge $Q$is proportional to the product of the two charge and inversely proportional to the square of the distance between them as,

$F=\frac{1}{4蟺{蔚}_0}\frac{qQ}{r^2}$ 鈥︹�︹��.. (1)

If the two charges have same sign that is positive or negative then the force between them is repulsive and directed radially outward.

As the charges are lying at the corners of polygon and charges are alike, and also placed at the same distance from the test charge at the center. So, force between each corner charge and the test charge is same and repulsive in nature.

All the charge apply the same force on the test charge in opposite direction. So, total force on the test charge is zero.

The force on the test charge at the center, for the condition, the charge which is at 6 o clock is removed is obtained as follows.

There is only charge present exactly opposite to the test charge, which is due to the charge at 12 o clock. Now the force at the test charge for the given condition is given by

$F=\frac{1}{4蟺{蔚}_0}\frac{qQ}{r^2}$

If the polygon has 13 sides, then also the force on the charge at the center is 0. This is because of the symmetry of the system. When all the charges are at the same distance from the test charge, the force on the center charge becomes zero.

It can be understood via a circular ring with uniformly distributed charge on it. The force on the center of the ring is zero due to symmetry. This is because the ring is made up of combination of even or odd number of infinite parts.

Thus, the force on the test charge at the center of the polygon is zero.

If there are 13 charges on the corners of a polygon, then electric field due to the 13 charges at the corners at the test charge will act in different directions, due to different position of the test charge with respect to corner charges.

If net force is computed on the test charge, it will sum up to zero.

As an example, electric force due to 13 charge, at the center is 0. This is because, the force on the test charge due to the other 12 corner charges is balanced by 13^th charge.

So, if any one charge from corner of the polygon is removed, the resultant force will not be equal to 0. Then, in this condition, the net force due to the remaining 12 charge is given by following equation.

$F=\frac{1}{4蟺{蔚}_0}\frac{qQ}{r^2}$
