A battery of emf εand internal resistance r is hooked up to a variable "load" resistance,R . If you want to deliver the maximum possible power to the load, what resistance R should you choose? (You can't change e and R , of course.)

Short Answer

Expert verified

The maximum power is delivered to the load when the internal resistance of the battery is equal to the load resistance.

Step by step solution

01

Write the given data from the question.

The emf of the battery isε .

Internal resistance of the battery isr .

Load resistance is R .

02

Determine the value of the resistance to deliver the maximum power to load.

Consider the circuit diagram shown below.

The current in the above circuit is given by,

i=ER+r

The power deliver to the load is given by,

P=i2R

Substitute ER+rfor into above equation.

p=ER+r2R …… (1)

The maximum power can be delivered to the load under the conditiondPdR=0.

Now differentiate the equation (1) with respect to R,

dPdR=R+r2E2+E2R×2R×rR×r4dPdR=R+r2E2+2E2R×rR×r4

Substitute the above equation equal to zero.

dPdR=0R+r2E2-2E2R4R+rR+r=0R+rE2R+r-2R=0R+rE2r-R=0

Solve further as,

r=R=0R=r

Hence the maximum power is delivered to the load when the internal resistance of the battery is equal to the load resistance.
