A square loop (side a) is mounted on a vertical shaft and rotated at angular velocity Ӭ (Fig. 7.19). A uniform magnetic field B points to the right. Find theεtfor this alternating current generator.

Short Answer

Expert verified

The induced emf in the square loop is .Ba2Ó¬sinÓ¬t

Step by step solution

01

Write the given data from the question.

The uniform magnetic field is B .

The side of the square loop is a .

The angular velocity is Ó¬.

02

Calculate the generated emf in the square loop.

εt=-ddt(BAcosӬt)The area of square loop,A=a2 .

The square loop is moving at angle with angular velocity in time

tθӬt.

The magnetic flus through the loop is given by,

role="math" localid="1657618600560" ϕ=BAcosθ

Substitute Ӭtfor θinto above equation.

ϕ=BAcosθ

According to the Faraday’s law, the induced emf in any closed loop is equal to the negative of the rate of change of flux in the circuit.

ε(t)=-dϕdt

Substitute ϕ=BAcosӬtfor ϕinto above equation.

εt=-ddt(BAcosӬt)

Substitute for into above equation.

role="math" localid="1657619049126" εt=-ddt(BAcosӬt)εt=-Ba2-sinӬt.Ӭεt=-Ba2sinӬt

Hence the induced emf in the square loop is Ba2Ó¬sinÓ¬t.
