(a) What is the fastest transverse wave that can be sent along a steel wire? For safety reasons, the maximum tensile stress to which steel wires should be subjected is 7.00x1018N/m2.The density of steel is7800kg/m3. (b) Does your answer depend on the diameter of the wire?

Short Answer

Expert verified
  1. Fastest transverse wave that can be sent along a steel wire is 30 m/s.
  2. The answer does not depend on the diameter of the wire.

Step by step solution

01

Given data

Tensile stress isTstress=7.00×108N/m2

Density of steel isÒÏ=7800kg/m3

02

Understanding the concept of the velocity of the wave

We use the concept of velocity of a transverse wave. We use the relation between density, area, and linear mass density. Then plugging the values in the equation of wave velocity we can find the maximum velocity that can be sent through the steel.

Formulae:

The velocity of the string, v=Tμ.......(1)

The linear density of the string, role="math" localid="1660983986609" μ=ÒÏA.......(2)

03

Step 3(a): Calculation of the fastest transverse wave

We know tensile stress is tension per unit area that is given as:

Tstress=TAT=TstressA

Substituting the value of tension and linear density from equation (2) in equation (1), we get the maximum velocity as given:

vmax=TstressAÒÏA=TstressÒÏ=7.00×1087800=300m/s

Hence, the value of maximum velocity is 300 m/s

04

Step 4(b): Checking whether the velocity depend on diameter of the wire

The above equation is independent of the area, so the answer doesn’t depend on the diameter of the wire.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Two sinusoidal waves of the same frequency are to be sent in the same direction along a taut string. One wave has amplitude of,5.0 mm the other.8.0 mm (a) What phase differenceϕ1between the two waves results in the smallest amplitude of the resultant wave? (b) What is that smallest amplitude? (c) What phase differenceϕ2results in the largest amplitude of the resultant wave? (d) What is that largest amplitude? (e) What is the resultant amplitude if the phase angle is ((ϕ1-ϕ2)/2)?

The functiony(x,t)=(15.0cm)cos(ττ³æ-15ττ³Ù), with x in meters and t in seconds, describes a wave on a taut string. What is the transverse speed for a point on the string at an instant when that point has the displacement y=+12.0cm?

A sinusoidal wave is sent along a string with a linear density of 2.0 g/m. As it travels, the kinetic energies of the mass elements along the string vary. Figure (a)gives the ratedK/dtat which kinetic energy passes through the string elements at a particular instant, plotted as a function of distance x along the string. Figure (b)is similar except that it gives the rate at which kinetic energy passes through a particular mass element (at a particular location), plotted as a function of time t. For both figures, the scale on the vertical (rate) axis is set by Rs = 10 W. What is the amplitude of the wave?

Two waves are described byy1=0.30sin[Ï€5x-200t]and y3=0.30sin[Ï€(5x-200t)+Ï€/3], where,y1,y2and xare in meters and t is in seconds. When these two waves are combined, a traveling wave is produced. What are the (a) amplitude, (b) wave speed, and (c) wavelength of that travelling wave?

The speed of electromagnetic waves (which include visible light, radio, and x rays) in vacuum is30x108m/s. (a) Wavelengths of visible light waves range from about 700 nmin the violet to about 700 nmin the red. What is the range of frequencies of these waves? (b)The range of frequencies for shortwave radio (for example, FM radio and VHF television) is 1.5to 300 MHz . What is the corresponding wavelength range? (c) X-ray wavelengths range from about 5.0nmto about1.0x10-2nm . What is the frequency range for x rays?
