1. The mass of the hoop,$\mathrm{m}=2\mathrm{kg}$ .
2. The radius of the hoop,$R=0.5m$.
3. The mass of the bar, $m=2kg$.
4. The length of the bar,$\mathrm{R}=0.5\mathrm{m}$.
5. The period of the rotation of the rigid structure, $\mathrm{T}=2.5\mathrm{s}$.

Find the rotational inertia of the rigid structure by adding the rotational inertia of the circular hoop and the square about the axis of rotation. Then by using the given period of rotation of the structure, we can find its angular speed. By using the relation between $\mathbf{\text{³¢,±õ²¹²Ô»åÓ¬}}$we can find the angular momentum of the rigid structure.

Formula:

(a)

The rotational inertia of the circular hoop is

$\begin{array}{c}{\text{I}}_1={\text{I}}_{\text{com}}+{\text{mh}}^2\\ ⇒{\text{I}}_1=\frac{1}{2}{\text{mR}}^2+{\text{mR}}^2\\ ⇒{\text{I}}_1=\frac{3}{2}{\text{mR}}^2\end{array}$

The square is made up of four bars, out of which one is along the axis of rotation. So its moment of inertia is zero.

${\text{I}}_2=0$

Therotational inertiaof the other side which is parallel to the axis of rotation is

$\begin{array}{c}\text{I}={\text{I}}_{\text{com}}+{\text{mh}}^2\\ ⇒{\text{I}}_3=0+{\text{mR}}^2\\ ⇒{\text{I}}_3={\text{mR}}^2\end{array}$

Therotational inertiaof the bars which are perpendicular to the axis of rotation are same and are

$\begin{array}{c}{\text{I}}_4={\text{I}}_5=\frac{1}{12}{\text{mR}}^2+\text{m}{\left(\frac{\text{R}}{2}\right)}^2\\ ⇒{\text{I}}_4={\text{I}}_5=\frac{1}{3}{\text{mR}}^2\end{array}$

Therefore, the total rotational inertia of the rigid structure is

$\begin{array}{c}\text{I}={\text{I}}_1+{\text{I}}_2+{\text{I}}_3+{\text{I}}_4+{\text{I}}_5\\ ⇒\text{I}=\frac{3}{2}{\text{mR}}^2+0+{\text{mR}}^2+\frac{1}{3}{\text{mR}}^2+\frac{1}{3}{\text{mR}}^2\\ ⇒\mathrm{I}=\frac{19}{6}=1.66~1.6{\mathrm{kgm}}^2\end{array}$

(b)

The angular speed of the rigid structure is

$\begin{array}{c}\text{Ó¬}=\frac{\text{»åθ}}{\text{dt}}\\ ⇒\text{Ó¬}=\frac{2\text{Ï€}}{2.5}\\ ⇒\text{Ó¬}=2.5\frac{\text{rad}}{\text{s}}\end{array}$

The angular momentum of the rigid structure is,

$\begin{array}{c}\text{L}=\text{±õÓ¬}\\ ⇒\text{L}=1.6×2.5\\ ⇒\mathrm{L}=4.0\frac{{\mathrm{kgm}}^2}{\mathrm{s}}\end{array}$
