A 20 kg0object is acted on by a conservative force given by F=-3.0x-5.0x2, with Fin newton and x in meters. Take the potential energy associated with the force to be zero when the object is at x=0. (a) What is the potential energy of the system associated with the force when the object is at x=2.0 m? (b) If the object has a velocity of 4.0 m/sin the negative direction of the x-axis when it is at x=5.00 m, what is its speed when it passes through the origin? (c) What are the answers to (a) and (b) if the potential energy of the system is taken to be -8.0 Jwhen the object is at x=0?

Short Answer

Expert verified

a) The P.E. of the system associated with the force when the object is at x=2.0 m is 19.4 J

b) The speed of the object when it passes through the origin is 6.37 m/s

c) Answer for part a) will be 11.4 J and that for part b) will be 6.37 m/s when P.E. of the system when the object is at x=0 is-8.0 J.

Step by step solution

01

The given data

The mass of an object is m=20 kg

The force applied to an object isF=-3.0x-5.0x2

The potential energy of the object at x=0 is,U0=0J

The velocity of an object is v=4.0 m/s in the negative direction of the x-axis when it is at x=0

02

Understanding the concept of work done

Using the formula for work done on a system by an external force, we can find the stopping distance of an automobile.

Formulae:

The potential energy or work done by the system,U(x)=∫F(x)dx (1)

The total energy of the system,E=12mv2+U(x) (2)

From the law of conservation of energy,

Ei=Ef (3)

03

a) Calculation of the potential energy of the system

We are given that the force applied to an object isF=-3.0x-5.0x2

Then P.E associated with it is using equation (1) is given as:

Ux=∫xixf-3.0x-5.0x2dx=-3.0x22-5.0x33-U0=3.0x22+5.0x33+U0

Ux=2.0m=3.02.0m22+5.02.0m33+0=19.4J

Therefore, the P.E. of the system associated with the force when the object is at x=2.0 m is equal to 19.4J

04

b) Calculation of the speed of the object

But, it has the speed ofv=4.0 msatx=5.0 m

From equation (3), we can get the initial speed of the object as follows:

Ei(x=0 m)=Ef(x=5 m)12mv02+U0=12mv2+U(x=5 m)1220kgv02+01220kg4.0ms2+3.05m22+5.05m33+0v02=40.58m22sv0=6.37ms

Therefore, the speed of an object when it passes through the origin is 6.37 m/s

05

c) Calculation of the parts (a) and (b) for potential energy -8.0J

From part a), we can write that,

Ux=2m=3.02m22+5.02m33+U0

IfU0=-8Jthen, the new potential energy is given as:

Ux=2m=3.02m22+5.02m33-8J=11.4J

v0will be the same as before becauseU0on both sides of the equation part (b) cancels out.

So it is independent ofU0.

Therefore, the answer for part a) will be 11.4 J and that for part b) will be 6.37 m/s.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

A 1500 kgcar starts from rest on a horizontal road and gains a speed of 72 km/hin 30 s. (a) What is its kinetic energy at the end of the 30 s? (b) What is the average power required of the car during the 30 sinterval? (c) What is the instantaneous power at the end of the 30 sinterval, assuming that the acceleration is constant?

The maximum force you can exert on an object with one of your back teeth is about 750 N. Suppose that as you gradually bite on a clump of licorice, the licorice resists compression by one of your teeth by acting like a spring for which k=2.5×105N/m. Find (a) the distance the licorice is compressed by your tooth and (b) the work the tooth does on the licorice during the compression. (c) Plot the magnitude of your force versus the compression distance. (d) If there is a potential energy associated with this compression, plot it versus compression distance. In the 1990s the pelvis of a particular Triceratops dinosaur was found to have deep bite marks. The shape of the marks suggested that they were made by a Tyrannosaurus rex dinosaur. To test the idea, researchers made a replica of a T. rex tooth from bronze and aluminum and then used a hydraulic press to gradually drive the replica into cow bone to the depth seen in the Triceratops bone. A graph of the force required versus depth of penetration is given in Fig. 8-71 for one trial; the required force increased with depth because, as the nearly conical tooth penetrated the bone, more of the tooth came in contact with the bone. (e) How much work was done by the hydraulic press—and thus presumably by the T. rex—in such a penetration? (f) Is there a potential energy associated with this penetration? (The large biting force and energy expenditure attributed to the T. rex by this research suggest that the animal was a predator and not a scavenger.)
