An oscillating block–spring system takes 0.75 sto begin repeating its motion.

  1. Find the period.
  2. Find the frequency in hertz.
  3. Find the angular frequency in radians per second.

Short Answer

Expert verified
  1. Time period is 0.75 sec.
  2. Frequency in Hz is 1.3 Hz.
  3. Angular frequency in rad/sec is 8.4 rad/s.

Step by step solution

01

Stating the given data

The time period of oscillation is 0.75 sec.

02

Understanding the concept of simple harmonic motion

The time period is the time required to complete one complete cycle. We use this concept to find the time period. Once we know the time period, we can find the frequency and angular frequency by using the basic formula in SHM.

Formula:

The time period of a body in oscillation

T=1f (i)

Angular frequency of a body in oscillation

Ӭ=2×π×f (ii)

03

a) Calculation of time period

Time taken to complete one cycle isthetime period that is the time taken for repeatingthemotion.

So, the time period is T=0.75sec.

04

b) Calculation of frequency

Using equation (i), the frequency of a body is given as

f=1T=10.75=1.3Hz

Hence, the value of frequency is 1.3Hz.

05

c) Calculation of angular frequency

Using equation (ii), the angular frequency is given as

Ӭ=2π×1.3=8.17rad/sec

Hence, the value of angular frequency is 8.17rad/sec.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91Ó°ÊÓ!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

A massless spring hangs from the ceiling with a small object attached to its lower end. The object is initially held at rest in a position yisuch that the spring is at its rest length. The object is then released from yiand oscillates up and down, with its lowest position being 10cmbelowyi

(a) What is the frequency of the oscillation?

(b) What is the speed of the object when it is 8.0cmbelow the initial position?

(c) An object of mass 300gis attached to the first object, after which the system oscillates with half the original frequency. What is the mass of the first object?

(d) How far below yiis the new equilibrium (rest) position with both objects attached to the spring?

In Figure, a 2.50 kgdisk of diameter D=42.0 cmis supported by a rod of length L=76.0 cmand negligible mass that is pivoted at its end.

  1. With the massless torsion spring unconnected, what is the period of oscillation?
  2. With the torsion spring connected, the rod is vertical at equilibrium. What is the torsion constant of the spring if the period of oscillation has been decreased by 0.500s?

An object undergoing simple harmonic motion takes 0.25 sto travel from one point of zero velocity to the next such point. The distance between those points is 36 cm.

(a) Calculate the period of the motion.

(b) Calculate the frequency of the motion.

(c) Calculate the amplitude of the motion.

An automobile can be considered to be mounted on four identical springs as far as vertical oscillations are concerned. The springs of a certain car are adjusted so that the oscillations have a frequency of 3.00 Hz.

  1. What is the spring constant of each spring if the mass of the car is 1450 kgand the mass is evenly distributed over the springs?
  2. What will be the oscillation frequency if five passengers, averaging 73.0 kgeach, ride in the car with an even distribution of mass?

A simple harmonic oscillator consists of a 0.50 kgblock attached to a spring. The block slides back and forth along a straight line on a frictionless surface with equilibrium point x=0. At t=0the block is at x=0and moving in the positive x direction. A graph of the magnitude of the net forceF→on the block as a function of its position is shown in Fig. 15-55. The vertical scale is set by FS=75.0N. What are (a) the amplitude and (b) the period of the motion, (c) the magnitude of the maximum acceleration, and (d) the maximum kinetic energy?
