1. Mass of proton,$m_p=1u$
2. Charge of proton,$q_p=+e$
3. Mass of deuteron,$m_d=2u$
4. Charge of deuteron,$q_d=+e$
5. Mass of $伪$particle, $m_{鈭�}=4u$
6. Charge of $伪$particle,$q_{鈭�}=+2e$

For a charge circulating in a magnetic field, the centripetal force is provided by magnetic force. By using this concept, we can find the radius of the circular path of each particle and then the required ratios.

Formula:

1. Magnetic force,$F_B=qvB$
2. Centripetal force,$F=\left(m{v}^2\right)/r$

For a charge circulating in a magnetic field, centripetal force is provided by the magnetic force.

Magnetic force

$F_B=qvB$ 鈥�(颈)

Centripetal force

$F=\left(m{v}^2\right)/r$ 鈥�(颈颈)

Equating equation (i) and (ii),

$qvB=\left(m{v}^2\right)/r$

Rearranging the equation for radius r$r=\frac{mv}{qB}$

鈥�(颈颈颈)

Kinetic energy of the circulation particle is given by

$K=\frac{1}{2}m{v}^2$

$v=\sqrt{\frac{2K}{m}}$

Using in equation (iii), we get

$r=\frac{m}{qB}脳\sqrt{\frac{2K}{m}}$

$r=\frac{\sqrt{m}}{q}脳\frac{\sqrt{2K}}{B}$ 鈥�(颈惫)

It is given that the magnetic force and kinetic energy of each particle is the same. Applying equation (iv) to deuteron and proton, we get

$r_d=\frac{\sqrt{m_d}}{q_d}脳\frac{\sqrt{2K}}{B}$

Taking ratio r_d of r_p,

$\frac{r_d}{r_p}=\frac{\sqrt{m_d}}{q_d}脳\frac{q_p}{\sqrt{m_p}}$

Using all the given values, we get

$\frac{r_d}{r_p}=\frac{\sqrt{2}}{+e}脳\frac{+e}{\sqrt{1}}$

$\frac{r_d}{r_p}=1.414$

Ratio of the radius r_d of the deuteron path to the radius r_pof the proton path:

$\frac{r_d}{r_p}=1.414~1.4$

It is given that magnetic force and kinetic energy of each particle is the same. Applying equation (iv) to$伪$particle and proton, we get

$r_{伪}=\frac{\sqrt{m_{伪}}}{q_{伪}}脳\frac{\sqrt{2K}}{B}$

Taking ratio of $r_{伪}and{r}_p$:

$\frac{r_{伪}}{r_p}=\frac{\sqrt{m_{伪}}}{q_{伪}}脳\frac{q_p}{\sqrt{m_p}}$

Using all the given values, we get

$\frac{r_d}{r_p}=\frac{\sqrt{4}}{+2e}脳\frac{+e}{\sqrt{1}}$

Ratio of the radius $r_{伪}$of the alpha particle path to the radius r_p. of the proton path:

$\frac{r_{伪}}{r_p}=1.0$
