Chapter 28: Q71P (page 833)

Physicist S. A. Goudsmit devised a method for measuring the mass of heavy ions by timing their period of revolution in a known magnetic field. A singly charged ion of iodine makes 7revin a 45.0mTfield in 1.29ms. Calculate its mass in atomic mass units.

Short Answer

Expert verified

The mass of the iodine ion in atomic mass unit is m=127u.

Step by step solution

01

Given

  1. The number of revolutions of the charged iodine ion is n=7rev.
  2. The magnetic field magnitude is B=45.0mT=45.0脳10-3T.
  3. The period of revolution for the iodine ion is T=1.29ms=1.29脳10-3s.
02

Understanding the concept

By using formula for the period of revolution for the iodine ion, we can find the mass of the iodine ion.

Formula:

The period of revolution for the iodine ion is

T=2蟺mBq

03

Calculate the mass in atomic mass units

The period of revolution for the iodine ion is

T=2蟺mBq

Therefore, the mass of iodine ion is

localid="1662898371084" m=BqT2蟺

m=(45.0脳10-3T)(1.60脳10-19C)脳(1.29脳10-3s)(7脳(2蟺)脳(1.66脳10-27kg/u))

Where n=7rev is the number of revolutions.

Hence the mass of the iodine ion in atomic mass unit is m=127u.

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

Figure 28-28 shows the path of an electron in a region of uniform magnetic field. The path consists oftwo straight sections, each between a pair of uniformly charged plates, and two half-circles. Which plate isat the higher electric potential in

(a) the top pair of plates and

(b) the bottom pair?

(c) What is the direction of the magnetic field?

A 5.0渭Cparticle moves through a region containing the uniform magnetic field localid="1664172266088" -20i铃�mTand the uniform electric field 300j^ V/m. At a certain instant the velocity of the particle is localid="1664172275100" (17i铃�-11j铃�+7.0k铃�)km/s. At that instant and in unit-vector notation, what is the net electromagnetic force (the sum of the electric and magnetic forces) on the particle?

A stationary circular wall clock has a face with a radius of 15 cm. Six turns of wire are wound around its perimeter; the wire carries a current of 2.0 A in the clockwise direction. The clock is located where there is a constant, uniform external magnetic field of magnitude 70 mT (but the clock still keeps perfect time). At exactly 1:00 P.M., the hour hand of the clock points in the direction of the external magnetic field. (a) After how many minutes will the minute hand point in the direction of the torque on the winding due to the magnetic field? (b) Find the torque magnitude.

Figure 28-25 shows the path of a particle through six regions of uniform magnetic field, where the path is either a half-circle or a quarter-circle. Upon leaving the last region, the particle travels between two charged, parallel plates and is deflected toward the plate of higher potential. What is the direction of the magnetic field in each of the six regions?

Question: A wire lying along an xaxis fromx=0to x=1.00mcarries a current of 3.00鈥�A in the positive xdirection. The wire is immersed in a nonuniform magnetic field that is given by localid="1663064054178" B鈫�=(4.00Tm2)x2i^-(0.600Tm2)x2j^ In unit-vector notation, what is the magnetic force on the wire?
