• The radius of a circular orbit, r = 0.500m
• Magnetic field, B = 1.20 T
• Charge of the proton, $q=1.60×{10}^{-19}C$
• Mass of proton,$m_p=1.67×{10}^{-27}kg$

We can find the frequency of the oscillator by using the value of the magnetic field. We can find the kinetic energy by using the formula for the radius of the circle in which the proton moves and the kinetic energy of the proton by substituting the given values.

Formula:

Oscillator frequency, $f_{osc}=\frac{qB}{2{\mathrm{Ï€³¾}}_{\mathrm{p}}}$

The radius of the circle in which the proton moves, $r=\frac{mv}{\left|q\right|B}$

The kinetic energy of the proton,$K=\frac{1}{2}{m}_p{V}^2$

The oscillating frequency is given by:

$\begin{array}{rcl}{f}_{osc}& =& \frac{qB}{2{\mathrm{Ï€³¾}}_{\mathrm{p}}}\\ & =& \frac{\left(1.60×{10}^{-19}\right)\left(1.20\right)}{2\mathrm{Ï€}\left(1.67×{10}^{-27}\right)}\\ & =& 1.83×{10}^{7}Hz\end{array}$

The oscillator frequency is $1.83×{10}^{7}Hz$.

The radius oftheorbit in whichtheproton moves in a circular orbit is:

$r=\frac{m_{p}v}{\left|q\right|B}$

And the kinetic energy of the proton is:

$K=\frac{1}{2}{m}_p{v}^2$

Rearranging the equation for v :

$v=\sqrt{2K\overline{)m_p}}$

The radius becomes,

$$\begin{gathered} r=\frac{m_p\sqrt{2K\overline{)m_p}}}{\left|q\right|B} \\ r=\frac{\sqrt{2m_{p}K}}{\left|q\right|B} \end{gathered}$$

We can rearrange this equation to get kinetic energy as:

$\begin{array}{rcl}K& =& \frac{{\left(rqB\right)}^2}{2m_p}\\ & =& \frac{{\left[\left(0.500\right)\left(1.60×{10}^{-19}\right)\left(1.20\right)\right]}^2}{\left[2\left(1.67×{10}^{-27}\right)\left(1.60×{10}^{-19}\right)\right]}\\ & =& 1.72×{10}^{7}eV\end{array}$

The kinetic energy of the proton is $\begin{array}{rcl}& & 1.72×{10}^{7}eV\end{array}$.
