An unknown charge sits on a conducting solid sphere of radius 10 cm . If the electric field 15 cm from the center of the sphere has the magnitude 3103N/Cand is directed radially inward, what is the net charge on the sphere?

Short Answer

Expert verified

The net charge on the sphere is -7.510-9C.

Step by step solution

01

The given data

a) The radius of the solid sphere,r=10cm

b) The magnitude of the electric field,|E|=3103N/C

c) Distance of the electric field from the center of the sphere,r=15cm

02

Understanding the concept of the electric field

Using the concept of the electric field, we can get the net charge of the sphere by substituting the given values in the given formula.

Formula:

The magnitude of the electric field, |E|=q4蟺蔚0r2 (1)

03

Calculation of the net charge on the sphere

The electric field produced by the unknown charge at points outside the sphere is like the field of a point particle with a charge equal to the net charge on the sphere.

Thus, the net charge on the sphere is given by the equation (1) as follows:

q=4蟺蔚0r2E=0.15m23103N/C9109N.m2/C2=7.510-9C

The field points inward, toward the sphere center, so the charge is negative.

Hence, the value of the net charge isrole="math" localid="1657345115513" -7.510-9C .

Unlock Step-by-Step Solutions & Ace Your Exams!

  • Full Textbook Solutions

    Get detailed explanations and key concepts

  • Unlimited Al creation

    Al flashcards, explanations, exams and more...

  • Ads-free access

    To over 500 millions flashcards

  • Money-back guarantee

    We refund you if you fail your exam.

Over 30 million students worldwide already upgrade their learning with 91影视!

One App. One Place for Learning.

All the tools & learning materials you need for study success - in one app.

Get started for free

Most popular questions from this chapter

A non-conducting solid sphere has a uniform volume charge density P. Letrbe the vector from the center of the sphere to a general point Pwithin the sphere.

(a) Show that the electric field at Pis given byE=蚁谤/30(Note that the result is independent of the radius of the sphere.)

(b) A spherical cavity is hollowed out of the sphere, as shown in Fig. 23- 60. Using superposition concepts, show that the electric field at all points within the cavity is uniform and equal to E=蚁谤/30where ais the position vector from the center of the sphere to the center of the cavity.

Water in an irrigation ditch of width w = 3.22mand depth d= 1.04mflows with a speed of 0.207 m/s. The mass flux of the flowing water through an imaginary surface is the product of the water鈥檚 density (1000 kg/m3) and its volume flux through that surface. Find the mass flux through the following imaginary surfaces:

(a) a surface of areawd, entirely in the water, perpendicular to the flow;

(b) a surface with area 3wd / 2, of which is in the water, perpendicular to the flow;

(c) a surface of area wd / 2,, entirely in the water, perpendicular to the flow;

(d) a surface of area wd, half in the water and half out, perpendicular to the flow;

(e) a surface of area wd, entirely in the water, with its normalfrom the direction of flow.

Figure 23-61 shows a Geiger counter, a device used to detect ionizing radiation, which causes ionization of atoms. A thin, positively charged central wire is surrounded by a concentric, circular, conducting cylindrical shell with an equal negative charge, creating a strong radial electric field. The shell contains a low-pressure inert gas. A particle of radiation entering the device through the shell wall ionizes a few of the gas atoms. The resulting free electrons (e) are drawn to the positive wire. However, the electric field is so intense that, between collisions with gas atoms, the free electrons gain energy sufficient to ionize these atoms also. More free electrons are thereby created, and the process is repeated until the electrons reach the wire. The resulting 鈥渁valanche鈥 of electrons is collected by the wire, generating a signal that is used to record the passage of the original particle of radiation. Suppose that the radius of the central wire is 25 mm, the inner radius of the shell 1.4 cm, and the length of the shell 16 cm. If the electric field at the shell鈥檚 inner wall is,2.9104N/C what is the total positive charge on the central wire?

In Fig. 23-25, an electron is released between two infinite non-conducting sheets that are horizontal and have uniform surface charge densities(+)and(-), as indicated. The electron is subjected to the following three situations involving surface charge densities and sheet separations. Rank the magnitudes of the electron鈥檚 acceleration, greatest first.

Charge of uniform surface density 8.00nC/m2is distributed over an entire x-yplane; charge of uniform surface densityis 3.00nC/m2distributed over the parallel plane defined by z = 2.00 m. Determine the magnitude of the electric field at any point having a z-coordinate of

(a)1.00 m and

(b) 3.00 m.
