Figure 5-20 is given.

The problem is based on Newton鈥檚 second law of motion. The law states that the acceleration of an object is dependent on the net force acting upon the object and the mass of the object. Using Newton鈥檚 second law of motion and vector resolution, the answers to the above questions can be found.

Formula:${\mathbf{F}}_{\mathbf{net}}\mathbf{=}\mathbf{Ma}$

From graph line 5 represents vector $F_1$as it has a positive x component and negative y component. Also, the x components and y components are longer than the components in vector 6.

From graph line 7 represents vector ${\mathrm{F}}_2$as it has both x and y components negative. Also, both components are substantially smaller than vector 8.

X component of the net force is the addition of x components of vector ${\mathrm{F}}_1$and${\mathrm{F}}_2$

So x component is,

$$\begin{gathered} \mathrm{F}=3\mathrm{N}-1\mathrm{N} \\ =2\mathrm{N} \end{gathered}$$

y component of the net force is the addition of x components of vector ${\mathrm{F}}_1$and${\mathrm{F}}_2$

So y component is

Since the X component is positive and the Y component is negative, the resultant force is in the fourth quadrant.

Net force and acceleration would be in the same direction;therefore, the acceleration would also be in the fourth quadrant.
