1. Particle concentration,$n=2×{10}^8/c{m}^3$
2. Drift speed,$V_d=1×{10}^{5}m/sec$

The term "current density" refers to the quantity of electric current moving across a certain cross-section. To calculate the current density, we have to substitute the given values of particle concentration and speed in the formula of current density. We can find the direction of current density by considering the direction of beam particles. We can find the additional quantity required to calculate the total current by using the relation between current and current density.

Formulae:

The magnitude of the current density related to the drift velocity, $J=nq{V}_d$ ...(i)

where, n is the particle concentration, q is the charge of each particle, and $V_d$is the drift velocity.

The current density flowing through the area, $J=\frac{i}{A}$x ...(ii)

Since, the particles are doubly charged positive ions,

$$\begin{gathered} q=2e \\ =2×1.6×{10}^{-19}C \\ =3.2×{10}^{-19}C \end{gathered}$$

The particle concentration is given as,

$\begin{array}{l}n=2×{10}^8/{cm}^3\\ =\frac{2×{10}^8}{{10}^{-6}{m}^3}\\ =2×{10}^{14}/m^3\end{array}$

Substituting all the values in the formula of equation (i) for current density, we get the value as:

$$\begin{gathered} J=(2x{10}^{14}/m^3)(3.2x{10}^{-19}C)(1x{10}^{5}m/s) \\ =6.4A/m^2 \end{gathered}$$

Hence, the value of the current density is $6.4A/m^2$.

From equation (i), we get that the direction of the current density is same as the direction of the drift velocity for positive charge and opposite for the negative charge. As the beam particles are positively charged ions, so the direction of current density is same as the direction of the beam particles, that is, to the north.

From equation (ii), we can get the flow of the current formula as follows:

i=JA

where, A is the cross-sectional area of the beam.

Hence, if we want to calculate the total current, we must know the value of the cross-sectional area of the beam.
