In Figure, ε1=6.00V, ε2=12.0V ,R1=100Ω , R2=200Ω ,andR3=300Ω . One point of the circuit is grounded(V=0) .(a)What is the size of the current through resistance 1? (b) What is the direction (up or down) of the current through resistance 1? (c) What is the size of the current through resistance 2?(d) What is the direction (left or right) of the current through resistance 2? (e) What is the size of the current through resistance 3? (f) What is the direction of the current through resistance 3? (g) What is the electric potential at point A?

Short Answer

Expert verified

(a) Magnitude of the current flowing through the resistance . R1=0.0382A.

(b)Direction of the current flowing through the resistance R1. is downward.

(c) Magnitude of the current flowing through the resistanceR2=0.0109A .

(d) Direction of the current flowing through the resistance R2 is rightward.

(e) Magnitude of the current flowing through the resistance R3=0.0273A.

(f) Direction of the current flowing through the resistance R3is leftward.

(g) Electric potential at point Ais .+3.82V

Step by step solution

01

Given data:

The emf voltage, ε1=6.00V

The emf voltage, ε2=12.0V

The resistor, R1=100Ω

The resistor, R2=200Ω

The resistor, R3=300Ω

02

Understanding the concept:

Use the loop rule (Kirchhoff’s Voltage law) and the junction rule (Kirchhoff’s Current law) to find the current flowing through each resistance. Once you get the value of current,you can tell that in which direction it is moving.

Formula:

For any loop,∑V=0

At any junction∑Ii=∑Io

The Ohm’s law is, V=IR

03

(a) Calculate the size of the current through resistance 1:

Using the junction rule,you can say that

I1=I2+I3 ….. (1)

Using the loop rule,you can say that

ε1−I2R2−I1R1=0 ….. (2)

ε2−I3R3−I1R1=0 ….. (3)

Substituting the value ofI1 into equation (1).

ε1−I2R2−(I2+I3)R1=0ε1−(R2+R1)I2−I3R1=0(R2+R1)I2+I3R1=ε1

Substitute known values in the above equation.

300I2+100I3=6.0 ….. (4)

Now substitute equation (1) into equation (2).

ε2−I3R3−(I2+I3)R1=0ε2−I3(R3+R1)−I2R1=0I3(R3+R1)+I2R1=ε2

Substitute known values in the above equation.

100I2+400I3=12.0 ….. (5)

Solving equations (4) and (5), and multiply equation (5) with , you get,

300I2+100I3−300I2−1200I3=6.0−36.0−1100I3=−30.0I3=0.0273A

Substitute the above value into equation (4).

300I2+100(0.0273)=6.0300I2=6.0−2.73I2=0.0109A

Put0.0109A for I2and 0.0273Afor I3 into equation (1).

I1=I2+I3=(0.0109+0.0273)A=0.0382A

04

(b) Calculate the direction (up or down) of the current through resistance 1:

Since the magnitude of the current flowing through the resistanceR1 is 0.0382A, by using the diagram and the junction rule,you can say that the direction of the current flowing through the resistanceR1 is downward.

05

(c) Calculate the size of the current through resistance 2:

After solving the equations(1) and (2)simultaneously,you got the valueof thecurrent flowing through the resistanceR2 as 0.0109A.

06

(d) Calculate the direction (left or right) of the current through resistance 2:

Using the diagram and the junction rule,you can say that the direction of the current flowing through the resistance R2 is rightward.

07

(e) Calculate the size of the current through resistance 3:

After solving the equations(1) and (2)simultaneously, you got the value of current flowing through the resistanceR3 as 0.0273A.

08

(f) Calculate the direction of the current through resistance 3:

Using the diagram and the junction rule,you can say thatthe direction of the current flowing through the resistanceR3 is leftward.

09

(g) Calculate the electric potential at point A:

Electric potential across point Acan be given as,

VA=I1R1=0.0382V×100Ω=+3.82V

Hence,the electric potential at point A is.+3.82V
