Speed of target proton before collision is $v_{tx}=0\mathrm{m}/\mathrm{s}$.

Speed of projectile proton before collision is .$v_{px}=500\mathrm{m}/\mathrm{s}$

Angle made by projectile proton after collision with +x axis is, $\mathrm{θ}=60°$

Angle between target proton and projectile proton after collision is$90°$

Applying the law of conservation of momentum in x and y direction to the given system we can get two equations. Solving those two and inserting given values we can find the speed of target proton and the projectile proton after collision.

Formula:

$$\begin{gathered} P_{ix}=P_{fx} \\ {P}_{iy}=P_{fy} \end{gathered}$$

Let the mass of proton be m.

Since the angle made by the projectile proton after collision with +x axis is $\mathrm{θ}=60°$and the angle between the target proton and projectile proton after collision is $90°$,the angle made by the target proton after collision with +x axis is,$\mathrm{Î\pm }=\left(60-90\right)°=-30°$

According to the law of conservation of momentum,

$$\begin{gathered} P_{i,x}=P_{f,x} \\ m{v}_{px}+m{v}_{tx}=m{v}_p^{\text{'}}\cos \mathrm{θ}+m{v}_t^{\text{'}}\cos \mathrm{Î\pm } \\ 500=0.5v_p^{\text{'}}+0.866v_t^{\text{'}}.....\left(1\right) \\ {P}_{i,y}=P_{f,y} \end{gathered}$$

$$\begin{gathered} m{v}_{ty}+m{v}_{py}=m{v}_p^{\text{'}}\sin \mathrm{θ}+m{v}_t^{\text{'}}\sin \mathrm{Î\pm } \\ 0=v_p^{\text{'}}\sin \mathrm{θ}+v_t^{\text{'}}\sin \mathrm{Î\pm } \\ 0=v_p^{\text{'}}\sin \left(60°\right)+v_t^{\text{'}}\sin \left(-30°\right) \\ 0=0.866v_p^{\text{'}}-0.5v_t^{\text{'}}......\left(2\right) \end{gathered}$$

Solving equation (1) and (2) we get,

$v_t^{\text{'}}=433\mathrm{m}/\mathrm{s}$

Therefore, the speed of the target proton after collision is 433 m/s

From part (a),

$$\begin{gathered} 0=0.866v_p^{\text{'}}-0.5v_t^{\text{'}} \\ 0.866v_p^{\text{'}}=0.5v_t^{\text{'}} \\ {v}_t^{\text{'}}=\frac{0.5}{0.866}\left(433\right) \\ =250\mathrm{m}/\mathrm{s} \end{gathered}$$

Therefore, speed of the projectile proton after collision is 250 m/s
