Parent graph:The simplest form of the given function is called the parent function of that function and the graph of the parent function is called parent graph.

Domain: The set of all possible values for which given function defined is called domain.

Range: The set of all possible values of the given function is called range.

The given function is: $y=\frac{1}{2}\sqrt{x}$

In order to graph a function, find few co-ordinates by substituting values of ‘$x$’ and find finding the respective values of ‘$y$’.

$\begin{array}{c}\text{¹ó´Ç°ù â¶Ä‰}x=0,\\ y=\frac{1}{2}\sqrt{0}\\ =\frac{1}{2}\left(0\right)\\ =0\end{array}$

$\begin{array}{c}\text{¹ó´Ç°ù â¶Ä‰}x=1,\\ y=\frac{1}{2}\sqrt{1}\\ =\frac{1}{2}\left(1\right)\\ =0.5\end{array}$

$\begin{array}{c}\text{¹ó´Ç°ù â¶Ä‰}x=4,\\ y=\frac{1}{2}\sqrt{4}\\ =\frac{1}{2}\left(2\right)\\ =1\end{array}$

$\begin{array}{c}\text{¹ó´Ç°ù â¶Ä‰}x=9,\\ y=\frac{1}{2}\sqrt{9}\\ =\frac{1}{2}\left(3\right)\\ =1.5\end{array}$

$\begin{array}{c}\text{¹ó´Ç°ù â¶Ä‰}x=16,\\ y=\frac{1}{2}\sqrt{16}\\ =\frac{1}{2}\left(4\right)\\ =2\end{array}$

Plot these co-ordinates on a coordinate plane and join those points to get the required graph.

The parent function of$y=\frac{1}{2}\sqrt{x}$ is the simplest square root function.

That is,$y=\sqrt{x}$

Using graphing calculator, the graph of parent function$y=\sqrt{x}$ is given below.

Note: Since the parent function is just used for comparison, it is graphed using graphing calculator.

The parent function is multiplied by ‘$\frac{1}{2}$’, (a value less than 1 and greater than zero). So the graph$y=\frac{1}{2}\sqrt{x}$ is a vertical compression of $y=\sqrt{x}$.

Since ‘$x$’ is inside the root, the values inside the root must be positive.

Therefore, values of $x$is all positive real numbers including zero.

That is, $xâ‰\yen 0,\text{ â¶Ä‰â¶Ä‰}⇒x∈[0,∞)$.

Therefore, domain: $[0,∞)$

In $y=\frac{1}{2}\sqrt{x}$, the square root of$x$is multiplied by $\frac{1}{2}$.

As square root is always positive, the least value it takes is zero.

Therefore, find the least value of the function by substituting $x=0$in $y=\frac{1}{2}\sqrt{x}$.

$\begin{array}{c}y=\frac{1}{2}\left(\sqrt{0}\right)\\ =\frac{1}{2}\left(0\right)\\ =0\end{array}$

In $y=\frac{1}{2}\sqrt{x}$, the coefficient of $\sqrt{x}$is positive.

Therefore,$y$takes all the values in real numbers which are greater than or equal to zero.

Therefore,$yâ‰\yen 0,\text{ â¶Ä‰â¶Ä‰}⇒y∈[0,∞)$

Therefore, Range:$[0,∞)$
